Bestelnummer |
471210400
|
GTIN |
8717573872782
|
Production model |
WHR 918 ERV
|
Air flow rate |
217
|
Amperage |
5
|
Voedingsspanning |
230
|
Frequentie |
50
|
Geluidsniveau |
38
|
Energie klasse I |
A
|
Energie klasse II |
A+
|
Geschikt voor plafondmontage | |
Links/rechts oriëntatie omkeerbaar | |
Toevoerfilter volgens ISO 16890-1:2016 |
ISO Coarse
|
Afvoerfilter volgens ISO 16890-1:2016 |
ISO Coarse
|
Met thermische beveiliging | |
Geschikt voor wandmontage | |
Max. luchthoeveelheid bij 100 Pa |
180
|
Met constante druk regeling | |
Met constant volume regeling | |
Type vorstbeveiliging |
Verwarmingselement
|
Met bypass | |
Met verwarmingselement | |
Met bedrade bediening | |
Geschikt voor (extra) (RV) vochtsensor | |
Met interne (RV) vochtsensor | |
Geschikt voor zoneregelaar | |
Met zoneregelaar | |
Geschikt voor bedrade bediening | |
Vloermontage | |
Rendement toevoerfilter volgens ISO 16890-1:2016 |
65
|
Geschikt voor (extra) kooldioxide (CO2) sensor | |
Geschikt voor aansluiting cv-ketel | |
Dakaansluiting bovenkant | |
Dakaansluiting zijkant | |
Max. luchthoeveelheid bij 250 Pa |
120
|
Met interne kooldioxide (CO2) sensor | |
Max. luchthoeveelheid bij 200 Pa |
150
|
Max. luchthoeveelheid bij 150 Pa |
170
|
Max. luchthoeveelheid bij 300 Pa |
70
|
Woningaansluiting zijkant links | |
Woningaansluiting onderzijde | |
Woningaansluiting bovenkant | |
Woningaansluiting zijkant rechts | |
Geschikt voor draadloze afstandsbediening | |
Cos. phi conform EPN norm |
0.4
|
Met digitaal display | |
Rendement afvoerfilter volgens ISO 16890-1:2016 |
65
|
Ondersteunt protocol voor Modbus | |
Aantal fasen |
1
|
Spanning |
230
|
Nom. kanaaldiameter |
125-155
|
Elektrische aansluiting |
Aansluitsnoer Perilex
|
Type motor |
EC (elektronische commutatie)
|
Breedte |
558
|
Diepte |
299
|
Gewicht |
23
|
Hoogte |
680
|
Frequentie |
50
|
With bypass | |
With internal humidity (RH) sensor | |
Suitable for (extra) humidity (RH) sensor | |
Suitable for wall mounting | |
Efficiency exhaust filter according to ISO 16890-1:2016 |
65
|
Nominal duct diameter |
125-155
|
Exhaust filter according to ISO 16890-1:2016 |
ISO Coarse
|
Supply filter according to ISO 16890-1:2016 |
ISO Coarse
|
Height |
680
|
Weight |
23
|
Suitable for floor mounting | |
Depth |
299
|
Efficiency supply filter according to ISO 16890-1:2016 |
65
|
Suitable for (extra) carbon dioxide (CO2) sensor | |
Frequency |
50
|
Suitable for wireless remote control | |
With digital display | |
Residential connection, left side | |
Residential connection, underside | |
Residential connection, top | |
Residential connection, right side | |
Roof connection, top | |
Roof connection, side | |
Suitable for ceiling mounting | |
Width |
558
|
Left/right orientation reversible | |
Number of phases |
1
|
Housing material |
Steel
|
With thermal overload protection | |
Suitable for central heating boiler connection | |
Electrical connection |
Perilex connecting cord
|
Type of motor |
Electronically commutated (EC)
|
With zone controller | |
Suitable for wired control unit | |
With wired control unit | |
Supporting protocol for Modbus | |
Suitable for zone controller | |
With heating element | |
With constant volume flow control | |
Type of frost protection |
Heating element
|
Max. air volume at 100 Pa |
180
|
With constant pressure control | |
Voltage |
230
|
Max. air volume at 150 Pa |
170
|
Max. air volume at 300 Pa |
70
|
Max. air volume at 250 Pa |
120
|
With internal carbon dioxide (CO2) sensor | |
Max. air volume at 200 Pa |
150
|
Diepte |
299
|
Hoogte |
680
|
Gewicht |
22
|
Nom. kanaaldiameter |
125-155
|
Frequentie |
50
|
Aansluitingen woningzijdig |
Kanaaleind
|
Aansluitingen buitenluchtzijdig |
Kanaaleind
|
Materiaal behuizing |
Staal gecoat
|
Breedte |
558
|
Spanning |
230
|
Type motor |
EC (elektronische commutatie)
|
Elektrische aansluiting |
Aansluitsnoer met randaarde stekker
|
Energie-efficiëntieklasse |
A
|
Thermisch rendement conform EPN norm |
80
|
Opgenomen vermogen conform EPN norm |
0.0359
|
